"We enjoy the spa in all kinds of weather, especially when it’s snowing! It is like always being on vacation... but in your own back yard!"
—Deb, Hartford, CT











































Enjoy six vibrant colors one at a time, or use the color wheel to automatically rotate through the spectrum. Four lights are located in the footwell to illuminate the interior of the spa. Six lights above the water line create a dazzling display on the water’s surface.
Complicated water care is a thing of the past with the FROG system. Just replace bromine cartridges monthly and minerals four times a year to maintain sparkling clear water.
“We enjoy the spa in all kinds of weather, especially when it’s snowing! It is like always being on vacation…but in your own backyard!” –Deb, Hartford, CT
Always hot and ready spa water with an automatic heating and filtration system.
When a personal trainer designs a specific series of exercises, called circuit training, you get a more balanced workout. Similarly, in the seats of your Caldera spa you’ll find various types of jets in specific anatomical configurations. So, as you move from seat to seat, all of your body’s major muscle groups receive a completely satisfying massage.
Watch Video
| Specification | |
|---|---|
| Seating Capacity | 6 |
| Dimensions | 7'5" x 7'5" x 38" |
| Water capacity | 400 gallons / 1,514 liters |
| Weight (Dry) | 911 lbs. |
| Weight (Filled) | 5,297 lbs.* |
| Number of Jets | 45 |
| Hydromassage Jets | 4 AdaptaSsage® jets, 6 AdaptaFlo® jets, 35 Euro jets |
| Jet Pumps | 2 ReliaFlo® 2.5 HP; (5.2 BHP**); 1 dual-speed, 1 single-speed |
| Control System | Solid-state electronic with LED display |
| Heater Output | 4,000 watt |
| Electrical Requirements | 230v/50amp, 60Hz |
| GFCI Sub-panel | Included |
| Filter Size | 65 sq. ft. |
| FROG® Water Care System | Cartridge-ready |
| Monarch® CD Ozone System | Available option |
| Water Feature | Acquarella® waterfall |
| Aquatic Melodies® Entertainment | Optional Integrated MP3 sound system |
| Multi-color LED Lighting System | Ten multi-color points-of-light, interior (dimmable) |
| Energy Efficiency | Fully-insulated with FiberCor™ material, 2 lb. density; Certified to the California Energy Commission (CEC) in accordance with California law |
| Insulating Cover | 3.5" to 2.5" tapered, 2 lb.-density foam core |
| Spa Shell and EcoTech® Cabinet Options | Champagne Opal, White Pearl or White Sands with Coastal Gray, Espresso or Redwood |
Notes:
*Filled weight includes the weight of the occupants assuming an average weight of 175 lbs.
**Brake Horsepower (BHP) is the horsepower a pump motor achieves for a brief period upon start-up.
Watkins Manufacturing Corporation (“Watkins”) warrants to the original consumer purchaser (“you”) the following about your new Paradise Series spa, when purchased from an authorized dealer/service provider (“dealer”).
10 YEAR NO LEAK SHELL WARRANTY
Watkins warrants against water loss due to defects in the Paradise series spa shell for ten years.
7 YEAR SHELL SURFACE WARRANTY
Watkins warrants the acrylic surface material of the Paradise Series spas to be free from defects in materials and workmanship for seven years.
5 YEAR NO LEAK PLUMBING WARRANTY
Watkins warrants the Paradise Series spas against leaks caused by defects in manufacturing and workmanship for five years. This warranty specifically covers leaks from the wall fittings, jet fittings, internal plumbing, internal glue joints, drains, hoses, and all bonded parts.
3 YEAR COMPONENT WARRANTY
Watkins warrants the electrical components, pump(s), and other Paradise Series spa components against defects in materials and workmanship for three years. Some parts, most of which can be changed out without the use of tools, such as filter cartridges, filter lid, spa pillows, and cover locks are not included in this warranty, but are warranted to be free from defects in materials and workmanship at the time of delivery. Spa covers and other spa accessories are specifically excluded from this warranty, although they may be covered under other warranties. Please check with your Caldera dealer for details.
3 YEAR ENERGYPRO HEATER WARRANTY
Watkins unconditionally warrants the EnergyPro heater to be free from defects in materials and workmanship for three years. This warranty defines unconditional, with the exclusion of commercial or industrial use, and improper installation, as warranty coverage without exception provided that the component has failed to operate properly within the spa’s system.
3 YEAR EcoTech CABINET WARRANTY
Watkins warrants the EcoTech simulated wood cabinet to be free from defects in materials and workmanship for three years. This warranty specifically covers the EcoTech cabinet’s structural integrity (exclusive of surface stain), including the material and assembly. The EcoTech cabinet’s cosmetic finish is warranted to be free from defects in materials and workmanship at the time of initial delivery. Fading and weathering of the surface may naturally occur over time and are not considered defects. To restore the EcoTech cabinet’s appearance, refer to the spa Owner’s Manual for proper care and maintenance instructions.
2 YEAR LED LIGHTING SYSTEM WARRANTY
Watkins warrants the factory-installed LED light assemblies which consists of all lights within the spa to be free from defects in materials and workmanship for two years.
1 YEAR SPA FROG AND SOUND SYSTEM WARRANTY
Watkins warrants the factory-installed SPA FROG watercare system, and the Aquatic Melodies Integrated MP3 sound system, which includes the docking station, related components and speakers to be free from defects in materials and workmanship for one year.
EXTENT OF WARRANTY
This warranty extends only to the original consumer purchaser of the Caldera spa when purchased and originally installed within the boundaries of the United States. This warranty begins on your delivery date of the spa, but in no event later than one year from the date of purchase. This warranty terminates upon any transfer of ownership, or if the spa is installed or relocated outside the boundaries of the United States by the original consumer purchaser prior to the expiration of the warranty period.
WARRANTY PERFORMANCE
To make a claim under this warranty, contact your dealer. In the event you are unable to obtain service from the dealer, please contact Watkins Manufacturing Corporation at 1280 Park Center Drive, Vista, California, 92081, Attn: Customer Service Department (800) 669-1881 or via e-mail, custsvc@watkinsmfg.com. You must give Watkins and/or your dealer written notice of any warranty claim, along with a copy of your original purchase receipt indicating the date of the purchase, within ten (10) days of the time you discover the claim. Watkins reserves the right to inspect the malfunction or defect on location.
Watkins or its Authorized Service Agent will repair any defects covered by this warranty. Except as described herein, you will not be charged for parts, labor or the freight costs for parts necessary to repair the spa for defects covered by this warranty. In some cases, the servicing dealer may charge you a reasonable repairperson travel/service charge that is not covered by this warranty. Please contact the dealer for information regarding any such charges.
LIMITATIONS
Except as described above, this warranty does not cover defects or damage due to normal wear and tear, improper installation, alteration without Watkins’ prior written consent, accident, acts of God, misuse, abuse, commercial or industrial use, use of an accessory not approved by Watkins, failure to follow Watkins’ Pre-Delivery Instructions or Owner’s Manual, or repairs made or attempted by anyone other than an authorized representative of Watkins. Alteration includes, but is not limited to, any component or plumbing change, or electrical conversion. Visit www.calderaspas.com/fr or contact your dealer for a list of manufacturer approved accessories.
DISCLAIMERS
TO THE EXTENT PERMITTED BY LAW, WATKINS SHALL NOT BE LIABLE FOR LOSS OF USE OF THE SPA OR OTHER INCIDENTAL OR CONSEQUENTIAL COSTS, EXPENSES, OR DAMAGES, INCLUDING BUT NOT LIMITED TO THE REMOVAL OF ANY DECK OR CUSTOM FIXTURE OR ANY COST TO REMOVE OR REINSTALL THE SPA, IF NEEDED. Some states do not allow the exclusion or limitation of incidental or consequential damages, so the above limitations may not apply to you. ANY IMPLIED WARRANTIES, INCLUDING THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE, ARE LIMITED TO THE DURATION OF THE APPLICABLE WARRANTY STATED ABOVE. Some states do not allow limitations on how long an implied warranty may last, so the above limitations may not apply to you.
LEGAL REMEDIES
This warranty gives you specific legal rights, and you may have other rights which vary from state to state.
Caldera, Aquatic Melodies, EcoTech and EnergyPro are trademarks of Watkins Manufacturing Corporation. SPA FROG is a trademark of King Technology, Inc.
© 2011 Watkins Manufacturing Corporation
PN 62752 Rev. B 01/2011
